水滴宽腔粉碎机 Water drop wide chamber pulverizer
收藏
注:以上指标是满足以下情况的指标,原料品种玉米,水分 小于 13%,容重不低于 0.72t / m3。粉碎筛片筛 孔直径 φ2.0MM,开孔率不低于 33%。 水滴宽腔粉碎机性能特点: 1.水滴形粉碎式,定刀隔腔,在水滴形下部设有再粉碎室, 破坏环流,提高打击率; 2.操作门有安全互锁装置以保证操作门打开时电机无法启 动; 3.电动机和粉碎机转子安装在同一重型底座上,采用柱销 联轴器直联传动,转子经动平衡效验,并可正反向工作; 4.本机转子经特殊设计,具有两种不同的锤筛间隙。 Note: the above indexes are those that meet the following conditions: the raw material variety corn, water content less than 13%, bulk density not less than 0.72t/m3. Crush sieve sheet sieve Hole diameter phi 2.0MM, hole opening rate is not less than 33%. Water drop wide cavity crusher performance features: 1. Drop shaped crushing type, fixed knife cavity, in the lower part of the drop shaped re - crushing chamber, destroy circulation, improve the strike rate; 2. The operating door is equipped with safety interlock device to ensure that the motor cannot start when the operating door is opened. 3. The motor and the rotor of the crusher are installed on the same heavy base, and the column pin coupling is used for direct drive. 4. The rotor of this machine is specially designed with two different clearance of hammer and sieve. 技术参数及性能指标 Technical parameters and performance indicators
|
